Chetra T-20
CHETRA T11 used for industrial, oil-and-gas, hydro-technical and road-construction. Versions for forestry and reclamation operations are also available. This dozer is characterized with maneuverability, efficiency and flexibility. T11 has a special variant with hydrostatic transmission ensuring high perfomance of earthmoving operations within the whole speed range without traction cut off and loss of power.
Part number:
Supplier:
"Service of Industrial Machines" LLCDescription
TECHNICAL PARAMETERS OF CHETRA T-20 BULLDOZER
Model of engine YAMZ-238DE-2-28 / Cummins QSM11-C330
Diesel power, kW (HP) 243(330) - 246(335)
Fuel tank, liters 400
Weight (with attached implement), kg 33 250 (34 220)
Specific ground pressure (standart /LGP shoe), kgf/cm2 0,97 (0,71)
Width of standart shoe/ LGP shoe , mm 560/710
Road clearance, mm 540
ATTACHED IMPLEMENTS (OPTIONAL)
Semi-universal blade, W х H /m3 3976х1875/10,80
Angle blade, W х H /m3 -
Straight blade, W х H /m3 4378х1673/8,5
Variable power angle tilt VPAT blade (VPAT), W х H /m3 -
Universal blade, W х H /m3 4270х1920/11,7
Coal blade, W х H /m3 4270x1920/15
Rake blade, W х H /m3 -
Number of ripper shanks 1, 3 - shank ripper
Winch availability (traction force, tn.) Yes (30 tn)
DIMENSIONS (WITHOUT ATTACHED IMPLEMENTS)
Length (standart/LGP), mm 4605
Width (standart/LGP), mm 2696
Height (standart/LGP), mm 3885
Model of engine YAMZ-238DE-2-28 / Cummins QSM11-C330
Diesel power, kW (HP) 243(330) - 246(335)
Fuel tank, liters 400
Weight (with attached implement), kg 33 250 (34 220)
Specific ground pressure (standart /LGP shoe), kgf/cm2 0,97 (0,71)
Width of standart shoe/ LGP shoe , mm 560/710
Road clearance, mm 540
ATTACHED IMPLEMENTS (OPTIONAL)
Semi-universal blade, W х H /m3 3976х1875/10,80
Angle blade, W х H /m3 -
Straight blade, W х H /m3 4378х1673/8,5
Variable power angle tilt VPAT blade (VPAT), W х H /m3 -
Universal blade, W х H /m3 4270х1920/11,7
Coal blade, W х H /m3 4270x1920/15
Rake blade, W х H /m3 -
Number of ripper shanks 1, 3 - shank ripper
Winch availability (traction force, tn.) Yes (30 tn)
DIMENSIONS (WITHOUT ATTACHED IMPLEMENTS)
Length (standart/LGP), mm 4605
Width (standart/LGP), mm 2696
Height (standart/LGP), mm 3885
